ABB XT1B 160 TMD 63A 3 Pole Circuit Breaker Supplier in Bangladesh

Description

Product Name: ABB XT1B 160 TMD 63A 3 Pole Circuit Breaker Supplier in Bangladesh

Manufacturer: ABB

Product Description

The ABB SACE Tmax XT1B 160 TMD 63-630 63A 3 Pole Moulded Case Circuit Breaker (MCCB) is an industrial power distribution and protection device engineered for AC/DC networks. Equipped with a thermomagnetic release (TMD) unit featuring an adjustable thermal threshold and a fixed 630A instantaneous short-circuit current setting, this circuit breaker ensures reliable overload and short-circuit protection. Featuring a fixed three-pole configuration with front-mounted terminals, it offers secure installation and steady performance for commercial and industrial electrical distribution systems across Bangladesh.

Key Features

• Thermomagnetic Release (TMD): Features a TMD release unit for dependable overload and short-circuit protection in power distribution applications.

• 3-Pole Configuration: Designed for three-phase AC/DC power distribution systems.

• Superior Durability: Electrical Durability: Rated for 8,000 electrical operating cycles and 25,000 mechanical operating cycles.

• AC/DC Compatibility: Supports both alternating current and direct current operational requirements.

• SACE Tmax XT Series: Member of ABB’s SACE Tmax XT moulded case circuit breaker family.

Technical Specifications

• Brand: ABB

• Series: SACE Tmax XT

• Model: XT1B 160 TMD 63-630

• Product ID: 1SDA066805R1

• Order Code US and Canada: XT1BE3063AFF000XXX

• Product Type: Moulded Case Circuit Breaker (MCCB)

• Rated Current (In): 63 A

• Rated Instantaneous Short-Circuit Current Setting (Ii): 630 A

• Current Type: AC/DC

• Number of Poles: 3P

• Trip Unit Type: Thermomagnetic Release (TMD)

• Rated Operational Voltage: 690 V AC / 500 V DC

• Rated Frequency (f): 50 / 60 Hz

• Rated Insulation Voltage (Ui): 800 V

• Rated Impulse Withstand Voltage (Uimp): 8 kV

• Power Loss: 4.3 W per pole

• Version: Fixed (F)

• Terminal Type: Front

• Terminal Connection Type: Front

• Dimensions (W x H x D): 76.2 mm x 130 mm x 70 mm

• Weight: 1.1 kg

• Country of Origin: Italy

Conclusion

The ABB SACE Tmax XT1B 160 TMD 63-630 63A 3 Pole MCCB is designed for AC/DC power distribution systems requiring thermomagnetic overload and short-circuit protection. Its TMD release, fixed three-pole configuration, and front terminal design make it suitable for commercial and industrial electrical installations.
