ABB XT1N 160 TMD 100-1000 3 Pole Circuit Breaker Supplier in Bangladesh

Description

Product Name: ABB XT1N 160 TMD 100-1000 3 Pole Circuit Breaker Supplier in Bangladesh

Manufacturer: ABB

Product Description

The ABB XT1N 160 TMD 100-1000 3 Pole Moulded Case Circuit Breaker (MCCB) is a highly reliable power distribution component engineered for high-performance electrical systems. As a key member of the globally recognized SACE Tmax XT series, this device offers superior protection against overloads and short circuits for industrial and commercial applications. Featuring advanced thermomagnetic release technology, this MCCB ensures consistent operational safety, durability, and efficiency for your electrical infrastructure.

Key Features

• 3-Pole Fixed Configuration: Precision-engineered for stable 3-phase power distribution with a compact, fixed-mounting design.

• Thermomagnetic Protection: Equipped with a TMD release providing precise thermal and magnetic trip characteristics, essential for standard electrical distribution.

• AC/DC Versatility: Fully compatible with both AC and DC power systems, providing flexibility for diverse installation environments.

• Superior Operational Reliability: Rated for 8,000 electrical cycles and 25,000 mechanical cycles, guaranteeing long-term service life.

• Easy Installation: Features standard front-terminal connectivity with bolt-type terminals for secure and straightforward panel integration.

• Robust Standards: Manufactured in compliance with IEC 60947-2 standards, ensuring top-tier safety and performance in demanding conditions.

Technical Specifications

• Brand: ABB

• Series: SACE Tmax XT

• Model: XT1N 160 TMD 100-1000 3p

• Product ID: 1SDA067416R1

• Product Type: Moulded Case Circuit Breaker (MCCB)

• Standard: IEC 60947-2

• Current Type: AC/DC

• Terminal Connection: Front

• Terminal Type: Bolt

• Mounting Type: Fixed

• Rated Current (In): 100 A

• Rated Uninterrupted Current (Iu): 160 A

• Number of Poles: 3P

• Release Type: TMD (Thermomagnetic)

• Rated Instantaneous Short-Circuit Current (Ii): 1000 A

• Rated Operational Voltage: 690 V AC / 500 V DC

• Power Loss: 7 W per Pole

• Dimensions (W x H x D): 76.2 mm x 130 mm x 70 mm

• Weight: 1.1 kg

Conclusion

The ABB XT1N 160 TMD 100-1000 3 Pole Circuit Breaker is a dependable choice for professionals seeking robust circuit protection in Bangladesh. Its high-quality build, combined with proven SACE Tmax XT technology, makes it a superior investment for safeguarding your electrical assets against faults and operational hazards.
