ABB XT6N 800 Ekip Dip LSIG 800A 3 Pole IEC MCCB Best Price in Bangladesh

Description

Product Name: ABB XT6N 800 Ekip Dip LSIG 800A 3 Pole IEC MCCB Best Price in Bangladesh

Manufacturer: ABB

Product Description

The ABB XT6N 800 Ekip Dip LSIG 800A 3 Pole IEC MCCB is engineered for high-capacity power distribution and circuit protection under IEC 60947-2 standards. Part of the SACE Tmax XT series, this fixed three-pole automatic circuit breaker features front terminals, an 800A rated current, and an advanced electronic Ekip Dip LSIG solid-state release unit. It provides comprehensive protection—including long-time, short-time, instantaneous, and ground fault protection (LSIG)—for heavy-duty industrial and commercial electrical installations.

Key Features

• Solid-State Electronic Release (Ekip Dip LSIG): Equipped with an Ekip Dip LSIG electronic trip unit providing long-time, short-time, instantaneous, and ground fault protection.

• 3-Pole Configuration: Engineered specifically for three-phase power distribution networks.

• High Breaking Capacity: Delivers ultimate short-circuit breaking capacities up to 70 kA at 220/230/240 V AC and 36 kA at 380/415 V AC.

• Exceptional Durability: Built to withstand up to 20,000 mechanical operating cycles and 5,000 electrical operating cycles.

• ABB EcoSolutions: Designed with sustainable manufacturing practices, featuring a 60% recyclability rate according to EN45555 and zero waste to landfill validation.

Technical Specifications

• Brand: ABB

• Series: SACE Tmax XT

• Model: XT6N 800 Ekip Dip LSIG 800 3p F F

• Extended Product Type: XT6N 800 Ekip Dip LSIG In=800 3p F F

• Product ID: 1SDA100723R1

• Order Code / US & Canada Code: XT6NE3800GFF000XXX

• EAN: 8056221007993

• Product Type: Automatic Circuit Breaker (Moulded Case Circuit Breaker)

• Rated Current (In): 800 A

• Rated Uninterrupted Current (Iu): 800 A

• Number of Poles: 3P

• Release: Ekip Dip LSIG

• Release Type: Electronic (EL)

• Rated Operational Voltage: 690 V AC

• Short-Circuit Performance Level: N

• Rated Ultimate Short-Circuit Breaking Capacity (Icu): (220/230/240 V AC) 70 kA, (380/415 V AC) 36 kA, (440 V AC) 30 kA, (500/525 V AC) 25 kA, (690 V AC) 20 kA

• Rated Service Short-Circuit Breaking Capacity (Ics): (220/230/240 V AC) 70 kA, (380/415 V AC) 36 kA, (440 V AC) 30 kA, (500/525 V AC) 25 kA, (690 V AC) 20 kA

• Mechanical Durability: 20,000 cycles

• Electrical Durability: 5,000 cycles

• Terminal Connection Type: Front Terminals (Fixed Version)

• Standards: IEC 60947-2

• Dimensions (W x H x D): 210 mm x 268 mm x 103.5 mm

• Weight: 9.5 kg (Product Net Weight)

Conclusion

The ABB XT6N 800 Ekip Dip LSIG 800A 3 Pole IEC MCCB offers reliable, high-performance circuit protection for demanding industrial and commercial power distribution grids. With its sophisticated Ekip Dip LSIG electronic trip unit, robust breaking capacities, and compliance with IEC standards, it ensures maximum safety and operational continuity.
