OmniAccess Stellar AP1451 Wi-Fi 6E Access Point

Description

Product Name:  OmniAccess Stellar AP1451 Wi-Fi 6E Access Point

Manufacturer: ALCATEL-LUCENT ENTERPRISE

Product Description

The Alcatel-Lucent OmniAccess Stellar AP1451 is a premium, high-end indoor Wi-Fi 6E (802.11ax) access point. It is purposefully engineered to accommodate the very dense and high-capacity requirements of next-generation mobility and IoT-enabled networks. Currently, this product is categorized under Enterprise Networking within the Wireless Access Points classification.

This hardware unit leverages the expanded spectrum available in the 6GHz band to bring connectivity further. As a result, this Wi-Fi 6E solution delivers faster speeds, wider channels, and lower latency. The device operates with a powerful tri-radio architecture and includes dual 10Gbps uplinks for power resiliency and load sharing. Additionally, it integrates a dedicated scanning radio for security and a Bluetooth 5/Zigbee radio for location analytics and building automation.

Key Features

• • • Product Identification: Identified as an OmniAccess Stellar AP1451 Access Point.

    • Wi-Fi Generation: Built on the high-efficiency Wi-Fi 6E (802.11ax) standard.

    • Radio Configuration: Tri-radio configuration featuring 2.4 GHz (4×4), 5 GHz (8×8), and 6 GHz High (4×4).

    • Maximum Throughput: Supports a maximum aggregate wireless throughput up to 10 Gbps.

    • Resilient Interface: Equipped with dual 10Gbps multi-Gigabit autosensing uplink ports supporting Power over Ethernet (PoE) input for load sharing.

    • Management Modes: Supports deployment across three different management modes using a single software version to simplify IT operations.

    • Advanced Wireless Features: Supports 802.11ax features including OFDMA, DL/UL MU-MIMO, 1024-QAM modulation, Target Wake Time (TWT), and Radio Dynamic Adjustment (RDA).

    • Secure Storage: Integrated Trusted Platform Module (TPM 2.0) for the secure storage of network credentials and keys.

Technical Specifications

• • Product Name: Alcatel-Lucent OmniAccess Stellar AP1451

  • Manufacturer: ALCATEL-LUCENT ENTERPRISE

  • Brand: ALCATEL-LUCENT ENTERPRISE

  • Model / MPN: AP1451 / OAW-AP1451-RW / OAW-AP1451-US

  • AP Type: Indoor Premium Tri-Radio Wi-Fi 6E (802.11ax)

  • Wireless Data Rates:

    • 6 GHz High: Up to 4.8 Gbps (4SS HE160)

    • 5 GHz: Up to 4.8 Gbps (8SS HE80 or 4SS HE160)

    • 2.4 GHz: Up to 1147 Mbps (4SS HE40)

  • Supported Frequency Bands: Configured from 2.400 GHz up to 7.1250 GHz (Subject to country-specific regulatory restrictions).

  • Maximum Transmit Power (Per Chain): Up to 18 dBm on 2.4 GHz, 17 dBm on 5 GHz, and 16 dBm on 6 GHz (Limited by local regulatory requirements).

  • Interfaces:

    • 2 x multi-Gigabit 1/2.5/5/10 Gig autosensing (RJ-45) uplink ports Eth0 and Eth1 (PoE 802.3bt compliant)

    • 1 x USB 3.0 Type A (5V, 500mA)

    • 1 x RS-232 Console port

  • Antenna Gain: Integrated omni-directional antennas with a maximum gain of 3.9 dBi across 2.4 GHz, 5 GHz, and 6 GHz bands; features a maximum beamforming gain up to 12.93 dBi in the 5 GHz band.

  • Security: Provides enhanced enterprise security with WPA3, WPA2, 802.1X, Advanced Encryption Standard (AES), and wIPS/wIDS rogue AP containment.

  • Power Consumption: Maximum 49W via IEEE 802.3bt PoE (unrestricted functionality); scales down to 24W via standard 802.3at PoE with reduced radio and port capabilities.

  • Environmental Limits: Operating temperature from 0°C to 45°C; 10% to 90% non-condensing humidity.

  • Dimensions & Weight: 260mm x 260mm x 60mm (Single AP without packaging); Weight: 2370g.

  • Reliability (MTBF): 572,332 hours (65.33 years) at +25°C operating temperature.

  • Total Capacity: Supports up to 8 SSIDs per radio default (hardware ready for 16 SSIDs per radio) and up to 1,536 associated client devices per AP.

  • Category Path: Enterprise Networking / Wireless Access Points

  • Warranty: Hardware Limited Lifetime Warranty (HLLW)

Conclusion

Network architecture and IT requirements can vary significantly from enterprise to enterprise. Therefore, we highly encourage all corporate clients and IT professionals in Bangladesh to verify hardware compatibility before finalized planning.

Please reach out to our team directly to check current stock availability or request competitive pricing. Additionally, you can contact us anytime to receive an official proforma invoice tailored for your business in Bangladesh.
