OmniAccess Stellar AP1511 Wi-Fi 7 Access Point

Description

Product Name:  OmniAccess Stellar AP1511 Wi-Fi 7 Access Point

Manufacturer: ALCATEL-LUCENT ENTERPRISE

Product Description

The Alcatel-Lucent OmniAccess Stellar AP1511 is an entry-level indoor Wi-Fi 7 (802.11be) access point. It is purposefully engineered to solve modern connectivity challenges caused by a rising number of IoT devices and cutting-edge mobility technologies. Currently, this product is categorized under Enterprise Networking within the Wireless Access Points classification.

This hardware unit delivers exceptionally high throughput, robustness, and lower latency. It operates on the advanced Wi-Fi 7 standard, featuring tri-radio and tri-band technology across the 2.4 GHz, 5 GHz, and 6 GHz bands. Additionally, the unit includes one dedicated scanning radio to improve network security, alongside an integrated Bluetooth 5.4/Zigbee radio for location analytics and building automation.

Key Features

• Product Identification: Identified as an OmniAccess Stellar AP1511 Access Point.

• Wi-Fi Generation: Built on the advanced Wi-Fi 7 (802.11be) standard.

• Radio Configuration: Tri-radio support consisting of 2.4 GHz (2×2), 5 GHz (2×2), and 6 GHz (2×2).

• Maximum Throughput: Supports a maximum aggregate wireless throughput up to 9.22 Gbps.

• Multi-Gigabit Interface: Equipped with a multi-gigabit autosensing uplink port supporting up to 5G speeds with Power over Ethernet (PoE) input.

• Management Modes: Supports deployment across three management modes (Express, on-premises, or cloud) using a single software version.

• Advanced Wireless Features: Supports Multi-Link Operation (MLO), 4096-QAM, 320 MHz maximum channel bandwidth, and Radio Dynamic Adjustment (RDA).

• Secure Storage: Integrated Trusted Platform Module (TPM 2.0) for the secure storage of credentials and keys.

Technical Specifications

• Product Name: Alcatel-Lucent OmniAccess Stellar AP1511

• Manufacturer: ALCATEL-LUCENT ENTERPRISE

• Brand: ALCATEL-LUCENT ENTERPRISE

• Model / MPN: AP1511 / OAW-AP1511-RW / OAW-AP1511-US

• AP Type: Indoor Tri-Radio Wi-Fi 7 (802.11be)

• Wireless Data Rates:

  • 6 GHz: Up to 5.76 Gbps (2SS EHT320)

  • 5 GHz: Up to 2.882 Gbps (2SS EHT160)

  • 2.4 GHz: Up to 688 Mbps (2SS EHT40)

• Supported Frequency Bands: Configured based on regulatory domains (e.g., 2.400–2.4835 GHz, 5.150–5.850 GHz, and country-specific 6 GHz segments).

• Maximum Transmit Power: Up to 26 dBm on 2.4 GHz, 26 dBm on 5 GHz, and 27 dBm on 6 GHz (Limited by local regulatory requirements).

• Interfaces:

  • 1 x multi-gigabit 100M/1G/2.5G/5G IEEE 802.3bz compliant autosensing (RJ-45) uplink port Eth0 (PoE 802.3bt compliant, MACsec)

  • 1 x USB 2.0 Type C (5V, 500mA)

  • 1 x USB Type C console

• Antenna Peak Gain: Integrated omnidirectional antennas with 5.6 dBi (2.4GHz), 5.9 dBi (5GHz), and 6.4 dBi (6GHz).

• Security: Provides enhanced enterprise security with WPA3, WPA2, 802.1X, and MACsec.

• Environmental Limits: Operating temperature from 0°C to 50°C; 5% to 95% non-condensing humidity.

• Dimensions & Weight: 190mm x 190mm x 38mm (Single AP without packaging); Weight: 764g.

• Reliability (MTBF): 1,075,632 hours (122.79 years) at +25°C operating temperature.

• Total Capacity: Supports up to 16 SSIDs per radio and a total of 768 associated clients per AP.

• Category Path: Enterprise Networking / Wireless Access Points

• Warranty: Hardware Limited Lifetime Warranty (HLLW)

Conclusion

Network architecture and IT requirements can vary significantly from enterprise to enterprise. Therefore, we highly encourage all corporate clients and IT professionals in Bangladesh to verify hardware compatibility before finalized planning.

Please reach out to our team directly to check current stock availability or request competitive pricing. Additionally, you can contact us anytime to receive an official proforma invoice tailored for your business in Bangladesh.
