Product Name: ATFLOR 500mm Bare Finish Steel Raised Access Floor System Price in Bangladesh
Manufacturer: ATFLOR
Product Overview
The ATFLOR 500mm Bare Finish Steel Raised Access Floor System features a Class A fireproof classification, moisture-proof build, dust-proof properties, and corrosion prevention across product types FS440 to FS1000. This flooring system delivers high dimensional precision, strong loadability, and a shockproof design with an elegant appearance suitable for paving various brand-name top tiles.
Designed to solve traditional wiring issues such as aging wires and short circuits caused by embedded cement, brick, or wood floors, it provides high recyclability, convenient removal, cost efficiency, a long performance life, adjustable pedestal heights (with applied patent), assembly agility, ample underfloor space for cabling, and good interchangeability. Available panel size is 500 × 500 × 28 mm.
Key Features
-
Fireproof & Protective: Class A fireproof rating along with moisture-proof, dust-proof, and corrosion prevention qualities.
-
High Structural Integrity: Delivers high dimensional precision, strong loadability, and a shockproof build.
-
Versatile & Wiring Friendly: Eliminates traditional issues of aging wires and short circuits while accommodating various top tiles like carpet or PVC tiles.
-
Convenient Maintenance: Features high recyclability, convenient removal, agile assembly, and adjustable pedestal heights.
Characteristic Specifications
-
Panel: Cementitious infill welded steel shell featuring corner lock holes in all four corners, compatible with carpet, PVC tiles, or other desired finishes.
-
Pedestal: Die-casting cross aluminum top with a cross rubber gasket, supported by a steel structure base, with installation heights ranging from 50 mm to 1000 mm.
-
Locking Mechanism: Sharp top screws that securely lock the panel corners to the pedestal.
Technical Specification
| Model | Size (mm) | Fire Performance | Concentrated Load (LB) | Concentrated Load (N) | Concentrated Load (Kg) | Impact Load (N) | Ultimate Load (N) | Uniform Load (N/m²) | Rolling Load – 10 Times | Rolling Load – 10,000 Times |
| FS440 | 500 × 500 × 28 | A | $\ge 440$ | $\ge 1960$ | $\ge 200$ | $\ge 295$ | $\ge 5880$ | $\ge 9272$ | 1958 | 1566 |
| FS662 | 500 × 500 × 28 | A | $\ge 662$ | $\ge 2950$ | $\ge 301$ | $\ge 445$ | $\ge 8850$ | $\ge 1250$ | 2946 | 2356 |
| FS800 | 500 × 500 × 28 | A | $\ge 800$ | $\ge 3350$ | $\ge 363$ | $\ge 536$ | $\ge 11250$ | $\ge 16100$ | 3560 | 2670 |
| FS1000 | 500 × 500 × 28 | A | $\ge 1000$ | $\ge 4550$ | $\ge 450$ | $\ge 670$ | $\ge 13350$ | $\ge 23000$ | 4450 | 3560 |
Ideal Applications
-
5A class offices
-
Security Union Plazas
-
Futures Trading Buildings
-
Environments demanding heavy cabling and wiring
-
Flooring renovation projects in aging buildings
Conclusion
Ultimately, the ATFLOR 500mm Bare Finish Steel Raised Access Floor System delivers robust load-bearing performance, Class A fire safety, and advanced cable management for professional corporate offices, trading centers, and modernizing structures. By combining precision steel construction, locking corner designs, and adjustable pedestal heights up to 1000 mm, this system establishes a reliable, long-lasting foundation for environments requiring extensive wiring infrastructure.
