Fire-Lite ANN-RLY 10 Relay Board Price in BD

Description

Product Name: Fire-Lite ANN-RLY 10 Relay Board Price in BD

Country of Origin: United States

Product Overview

The Fire-Lite ANN-RLY (by Honeywell) is an addressable relay module designed for compatible Fire-Lite fire alarm control panels. It provides ten programmable Form-C relays to expand system control and auxiliary output capabilities. Furthermore, the module communicates via a supervised two-wire ANN-BUS serial interface. Consequently, it enables reliable execution of panel-assigned signaling and control functions within commercial life-safety installations.

Specifications & Features

• Brand & Model: Fire-Lite Alarms by Honeywell (MPN: ANN-RLY)

• Product Type: Addressable 10-Relay Expansion Module

• Relay Outputs: Features 10 programmable Form-C relays. Each relay can be assigned specific panel functions, including alarm, trouble, supervisory, AC loss, waterflow delay, input zones, and silenceable alarm.

• Relay Contact Rating: Rated for 2 A @ 30 VDC (Resistive) and 0.5 A @ 30 VAC (Resistive).

• Communication Interface: Operates on the Fire-Lite ANN-BUS two-wire serial interface. A single 4-conductor unshielded cable carries both 24 VDC power and data communications.

• Address Capacity: Supports up to 8 ANN-BUS devices per control panel.

• Operating Voltage & Current: Operates on 24 VDC. Draws 15 mA in standby mode and 75 mA in alarm mode.

• Power Supply Options: Powered directly by the host control panel or via a compatible remote 24 VDC power supply.

• Installation & Mounting: Mounts directly inside the main control panel chassis or within the battery compartment using the optional ANN-MBRLY mounting bracket.

• Environmental Limits: Operates in temperatures ranging from $32^\circ\text{F}$ to $120^\circ\text{F}$ ($0^\circ\text{C}$ to $49^\circ\text{C}$) with relative humidity up to 93% (non-condensing).

Agency Listings & Standards

• UL Listing: Listed to UL Standard 864 (9th Edition).

• Third-Party Approvals: FM Approved, ULC Listed, CSFM Listed, MEA Approved, and FDNY Approved.

Panel Compatibility

The Fire-Lite ANN-RLY is compatible with Fire-Lite control panels supporting the ANN-BUS protocol, including:

• ES Series: ES-50X, ES-200X

• MS Series: MS-5UD-3, MS-10UD-7, MS-9050UD, MS-9200UDLS, MS-9600LS, and MS-9600UDLS

• MRP Series: MRP-2001 and MRP-2002 agent release panels

Conclusion

The Fire-Lite ANN-RLY relay module offers 10 programmable Form-C relays over a 4-wire ANN-BUS connection. Therefore, it serves as an auxiliary relay expansion board for compatible Fire-Lite commercial fire alarm systems.
