Safeway AT5030C X-Ray Baggage Scanner Supplier in Bangladesh | Compact Security Solutions

Description

Product Name: Safeway AT5030C X-Ray Baggage Scanner Supplier in Bangladesh | Compact Security Solutions

Manufacturer: Safeway System

Product Description

The Safeway AT5030C X-Ray Baggage Scanner is a reliable security inspection system designed for screening briefcases, parcels, express mail, hand luggage, and small parcels without unpacking. Powered by an Intel Core i3 processor running on a flexible Windows operating system (XP, Win 7, Win 10 optional), it features a robust 140 kV X-ray generator and advanced digital processing tools. Widely utilized in government agencies, transport hubs, logistics centers, schools, and commercial venues across Bangladesh, the AT5030C delivers high steel penetration performance, precise material classification, and efficient daily threat screening.

Key Features

• Flexible Windows Platform: Powered by an Intel Core i3 (3.3 GHz) processor and 1TB hard disk storage, operating on compatible Windows systems for familiar and versatile control.

• Advanced Threat Detection: Supports drugs and explosives inspection together with intelligent material classification and organic/inorganic resolution.

• Comprehensive Image Processing: Offers advanced diagnostic tools including color/black and white, high/low penetration, super increase, inverse color, edge enhancement, and suspicious object marking.

• Massive Image Storage: Capable of storing up to 50,000 scanned images with multi-format export options (XF, PNG, BMP, JPEG, TIFF, GIF).

• Robust Self-Diagnosis & Device Diagnosis: Features automated fault self-checking and a diagnostic interface for key components including detectors, motors, infrared sensors, and keyboards.

• TIP (Threat Image Projection) Management: Supports customizable insertion of fictional threat items with adjustable injection intervals and motion judgment to monitor operator vigilance.

• Operator Management & Logs: Multi-level user administration allowing operator creation, modification, status control, and detailed usage log export.

• Built-in Training Function: Includes an automated training module designed for new learners to practice and improve identification skills.

Technical Specifications

• Brand: Safeway System

• Model: AT5030C

• Scanner Type: X-Ray Baggage & Small Parcel Inspection System

• Inspection Technology: Single-View X-Ray Imaging (1 Generator)

• X-Ray Generator Anode Voltage: 140 kV (Sealed oil cooling)

• Wire Resolution: 40 AWG

• Penetration Resolution: 34 AWG

• Spatial Resolution: Vertical 1.0 mm, Horizontal 1.0 mm

• Steel Penetration: 38 mm

• Conveyor Speed: Around 0.2 m/s

• Conveyor Maximum Load: 100 kg

• Single Inspection Dose: ≤ 4.5 µSv (µGy)

• Leakage Dose: < 1 µSv/h (µGy/h)

• Leakage Current: ≤ 5.0 mA

• Film Safety: Compliant with ASA/ISO 1600 Film Safety Standards

• Noise Level: No more than 60 dB

• Maximum Power Consumption: 0.8 kW

• Computer Configuration: Intel Core i3 3.3 GHz, 4GB RAM, 1TB Hard Disk

• Operating System: Windows XP, Win 7, Win 10 (Optional)

• Display Monitor: 21.5-inch LCD monitor with a resolution of 1920 x 1080

• Working Power: AC 220V (+10% to -15%), 50 Hz ±3 Hz

• Unit Weight: 320 kg

• Working Environment: 5°C to 40°C, 0% to 90% relative humidity

Applications

• Government Agencies and Public Offices

• Transport Hubs and Logistics Centers

• Courts, Procuratorates, and Prisons

• Embassies and Diplomatic Facilities

• Schools, Universities, and Educational Institutions

• Hospitals and Healthcare Facilities

• Gymnasiums and Exhibition Halls

• Hotels and Entertainment Venues

Conclusion

The Safeway AT5030C X-Ray Baggage Scanner combines a powerful Intel-based Windows platform, high steel penetration, and advanced software management to deliver reliable security screening. Designed for small baggage and parcel inspection points, it supports efficient security inspection and reliable baggage screening across commercial and government facilities.
