ABB AX25-30-10-80 3-Pole Contactor Best Price in Bangladesh

Description

Product Name: ABB AX25-30-10-80 3-Pole Contactor Best Price in Bangladesh

Manufacturer: ABB

Product Overview

The ABB AX25-30-10-80 is a 3-pole block contactor from the ABB AX series, designed for controlling 3-phase motors and power switching applications up to 690 V AC. Featuring an AC-operated coil with a control voltage of 220–230 V at 50 Hz and 230–240 V at 60 Hz, it is engineered for controlling motors up to 11 kW at 380/400 V AC (AC-3) and handling rated operational current AC-1 of 32 A at 690 V (40 °C).

Key Features and Benefits

• Reliable AC Coil Operation: Equipped with an AC-operated coil (220–230 V at 50 Hz / 230–240 V at 60 Hz) for consistent switching performance in industrial electrical panels.

• High Switching Capacity: Efficiently manages industrial requirements, rated for up to 11 kW at 380/400 V for AC-3 motor applications and rated operational current AC-1 of 32 A at 690 V (40 °C).

• Built-in Auxiliary Contacts: Features an integrated auxiliary contact structure (1 NO + 0 NC) for dependable status feedback and auxiliary control integration.

• Robust Mechanical and Electrical Design: Designed for a maximum electrical switching frequency of up to 1200 cycles/hour (AC-3) and mechanical switching up to 3600 cycles/hour to support continuous industrial operations.

Technical Specifications

• Product Line: ABB AX Series 3-Pole Contactors

• Model / Part Number: AX25-30-10-80 (1SBL931074R8010)

• Number of Poles: 3-Pole (3P)

• Main Contacts (NO / NC): 3 / 0

• Auxiliary Contacts (NO / NC): 1 / 0

• Rated Operational Voltage: Main Circuit 690 V / Auxiliary Circuit 690 V

• Rated Insulation Voltage (Ui): 690 V

• Conventional Free-air Thermal Current (Ith): 32 A at 40 °C (Open Contactor)

• Rated Operational Current AC-1 (Ie): 32 A at 690 V (40 °C)

• Rated Operational Current AC-3 (Ie): 25 A at 380/400 V (55 °C)

• Rated Operational Power AC-3 (Pe):

  • 380 / 400 V → 11 kW

  • 415 V → 11 kW

  • 440 V → 9 kW

  • 500 V → 9 kW

  • 690 V → 9 kW

• Rated Control Circuit Voltage (Uc): 220 … 230 V (50 Hz) / 230 … 240 V (60 Hz)

• Dimensions (H x W x D): 76.3 mm x 44 mm x 74 mm

• Product Net Weight: 0.326 kg

Ideal Applications

• Industrial Motor Control Centers (MCC) in Bangladesh

• Standard AC Motor Starters and Control Panels

• Factory Automation and Machinery Switchgear

• Industrial Motor Control and Power Switching Circuits

Conclusion

Ultimately, the ABB AX25-30-10-80 3-Pole Contactor delivers reliable AC coil operation, high switching capability, and reliable performance for industrial motor control and switching applications.
