OmniAccess Stellar AP1521 Wi-Fi 7 Access Point

Description

Product Name:  OmniAccess Stellar AP1521 Wi-Fi 7 Access Point

Manufacturer: ALCATEL-LUCENT ENTERPRISE

Product Description

The Alcatel-Lucent OmniAccess Stellar AP1521 is a next-generation indoor Wi-Fi 7 (802.11be) access point. It is engineered to solve modern connectivity challenges for enterprise users, IoT, and cutting-edge AI-powered applications. Currently, the product is categorized under Enterprise Networking within the Wireless Access Points classification.

This hardware unit delivers exceptionally high throughput, robustness, and lower latency. It operates on the new Wi-Fi 7 standard, featuring tri-radio technology across the 2.4 GHz, 5 GHz, and 6 GHz bands. Additionally, the unit includes a dedicated scanning tri-band radio and an integrated Bluetooth 5.4/Zigbee radio for location analytics and building automation.

Key Features

• Product Identification: Identified as an OmniAccess Stellar AP1521 Access Point.

• Wi-Fi Generation: Built on the advanced Wi-Fi 7 (802.11be) standard.

• Radio Configuration: Tri-radio support consisting of 6 GHz High (2×2:2), 5 GHz (4×4:4), and 2.4 GHz (2×2:2).

• Maximum Throughput: Supports a maximum wireless throughput up to 12.2 Gbps.

• Multi-Gigabit Interface: Equipped with a multi-gigabit autosensing uplink port supporting up to 10G speeds with Power over Ethernet (PoE) input.

• Management Modes: Supports deployment across three management modes (Express, on-premises, or cloud) using a single software version.

• Advanced Wireless Features: Supports Multi-Link Operation (MLO), 4096-QAM, 320 MHz maximum channel bandwidth, and Radio Dynamic Adjustment (RDA).

• Coexistence Technology: Features Advanced Cellular Coexistence (ACC) to minimize interference from commercial 3G/4G cellular networks.

Technical Specifications

• Product Name: Alcatel-Lucent OmniAccess Stellar AP1521

• Manufacturer: ALCATEL-LUCENT ENTERPRISE

• Brand: ALCATEL-LUCENT ENTERPRISE

• Model / MPN: AP1521

• AP Type: Indoor Tri-Radio Wi-Fi 7 (802.11be)

• Wireless Data Rates:

  • 6 GHz: Up to 5.76 Gbps (2SS EHT320)

  • 5 GHz: Up to 5.76 Gbps (2SS EHT160)

  • 2.4 GHz: Up to 688 Mbps (2SS EHT40)

• Supported Frequency Bands: Configured based on regulatory domains (e.g., 2.400–2.4835 GHz, 5.150–5.850 GHz, and country-specific 6 GHz segments).

• Maximum Transmit Power: Up to 26 dBm on 2.4 GHz, 26 dBm on 5 GHz, and 27 dBm on 6 GHz (Limited by local regulatory requirements).

• Interfaces:

  • 1 x multi-gigabit 100M/1G/2.5G/5G/10G IEEE 802.3bz compliant autosensing (RJ-45) uplink port Eth0 (PoE 802.3bt compliant, MACsec)

  • 1 x USB 2.0 Type C (5V, 500mA)

  • 1 x USB Type C console

• Antenna: Integrated omnidirectional antenna with a peak gain of 4.3 dBi

• Security: Provides enhanced enterprise security with WPA3 support

• Environmental Limits: Operating temperature from 0°C to 45°C; 5% to 95% non-condensing humidity

• Dimensions & Weight: 210mm x 210mm x 43mm (Single AP without packaging);

• Weight: 1020g

• Reliability (MTBF): 650,124 hours (74.22 years) at +25°C operating temperature

• Category Path: Enterprise Networking / Wireless Access Points

• Warranty: Hardware Limited Lifetime Warranty (HLLW)

Conclusion

Network architecture and IT requirements can vary significantly from enterprise to enterprise. Therefore, we highly encourage all corporate clients and IT professionals in Bangladesh to verify hardware compatibility before finalized planning.

Please reach out to our team directly to check current stock availability or request competitive pricing. Additionally, you can contact us anytime to receive an official proforma invoice tailored for your business in Bangladesh.

Please reach out to us directly to check stock availability or request the current price. Additionally, you can contact us to receive a formal proforma invoice in Bangladesh.
