Description
Product Name: ATFLOR 500mm Trunking Bare Steel Raised Access Floor System Price in Bangladesh
Manufacturer: ATFLOR
Product Overview
The ATFLOR 500mm Trunking Bare Steel Raised Access Floor System features an integrated side-trunking design for large cable management space, easy cable arrangement and fixing, and a very low system profile across product types FS440 to FS1000. Designed for environments requiring extensive overhead cable routing and large wire requirements, this flooring system allows for convenient wire connections at any point without cutting the floor and adapts to all types of plug socket terminals.
Main components include panels, trunk over plates, and corner cover plates, with optional accessories like electrical outlets, trunk bottom plates, corner bottom plates, and outlets. Available installation height ranges from 60 mm to 300 mm, and panel size is 500 × 500 × 28 mm.
Key Features
-
Integrated Trunking System: Features side-trunking by the panel with large cable management space, making arrangement and relocation effortless.
-
Flexible Wiring & Terminals: Convenient for connecting wires at any point without cutting the floor and suitable for all types of plug socket terminals.
-
Modular Components & Accessories: Comprises main components like panels, trunk over plates, and corner cover plates, with optional electrical outlets and trunk bottom plates.
-
Adjustable Low-Profile Height: Available in heights from 60 mm to 300 mm, making it ideal for new office buildings and surface remaking for wires in old buildings.
Characteristic Specifications
-
Trunking & Cable Layout: Trunkings can be applied at any unit according to the volume of cable and wire, solving traditional wiring hazards.
-
Applications: Excellent for 5A class office buildings, computer rooms, and locations requiring overhead routing and large wire requirements.
Technical Data Specification Table
| Model | Size (mm) | Fire Performance | Concentrated Load (LB) | Concentrated Load (N) | Concentrated Load (Kg) | Impact Load (N) | Ultimate Load (N) | Uniform Load (N/m²) | Rolling Load (N) | 10 Times | 10,000 Times |
| FS440 | 500 × 500 × 28 | A | $\ge 440$ | $\ge 1960$ | $\ge 200$ | $\ge 295$ | $\ge 5880$ | $\ge 9272$ | — | 1958 | 1566 |
| FS662 | 500 × 500 × 28 | A | $\ge 662$ | $\ge 2950$ | $\ge 301$ | $\ge 445$ | $\ge 8850$ | $\ge 1250$ | — | 2946 | 2356 |
| FS800 | 500 × 500 × 28 | A | $\ge 800$ | $\ge 3350$ | $\ge 363$ | $\ge 536$ | $\ge 11250$ | $\ge 16100$ | — | 3560 | 2670 |
| FS1000 | 500 × 500 × 28 | A | $\ge 1000$ | $\ge 4550$ | $\ge 450$ | $\ge 670$ | $\ge 13350$ | $\ge 23000$ | — | 4450 | 3560 |
Ideal Applications
-
5A class office buildings
-
Computer rooms
-
Environments demanding overhead cable routing and large wire requirements
-
Surface wire remodeling projects in aging office buildings
Conclusion
Ultimately, the ATFLOR 500mm Trunking Bare Steel Raised Access Floor System delivers robust structural load performance, Class A fire safety, and integrated side-trunking cable management for office buildings and technical rooms. By combining versatile wire connection points, customizable trunking units, and low-profile height options from 60 mm to 300 mm, this system provides an efficient foundation for overhead cable routing and large wire requirements.
