Earthing Works Installation Price in Bangladesh

Description

Product Name: Earthing Works Installation Price in Bangladesh

Product Overview

The Earthing Works service is specified for complete provision and installation. Furthermore, it features grounding components including site boring, material placement, cable terminations, and final electrical continuity testing. Consequently, it is designed to achieve grounding resistance below regulatory thresholds.

Key Features & Benefits

• Scope of Work: This entails complete provision and installation of grounding components. Additionally, it includes site boring, material placement, cable terminations, and final electrical continuity testing to achieve grounding resistance below regulatory thresholds.

• Resistance & Conductor: The system maintains a grounding resistance below 1 Ohm, complying with electrical safety standards. Moreover, it utilizes an SWG 4 solid bare copper wire conductor.

• Rod & Pit Lining: It is built with a high-conductivity solid copper earth rod. Furthermore, the earth pit features a 1.5-inch diameter medium-grade G.I. pipe lining.

• Cabling & Protection: The bonding cable consists of 50 rm BYA copper cable with green insulation. Moreover, it is protected by a 3/4-inch PVC or flexible pipe and secured with 3/4-inch metal saddles using Royal Plugs.

• Bus-Bars & Accessories: It incorporates a 12″ × 1.25″ × 3mm copper bar with a heavy-duty clamp alongside pre-drilled long and small GND bus-bars. Additionally, it includes high-conductivity Cable Lux terminations, soil enhancer compound, cable ties, labels, and fixings.

Technical Specifications

• Item Name: Earthing Works

• Quantity: 01 Lot

• Scope of Work: Complete provision and installation of grounding components, including site boring, material placement, cable terminations, and final electrical continuity testing to achieve grounding resistance below regulatory thresholds

• Grounding Resistance: <1 Ohm, complying with electrical safety standards

• Copper Conductor: SWG 4 solid bare copper wire

• Earth Rod: High‑conductivity solid copper rod

• Earth Pit Lining: 1.5” dia. G.I. pipe, medium grade

• Bonding Cable: 50 rm BYA copper cable with green insulation

• Cable Conduit: ¾” PVC or flexible pipe for mechanical protection

• Mounting Saddle: ¾” metal saddle with Royal Plug

• Copper Bar & Clamp: 12″ × 1.25″ × 3mm copper bar with heavy‑duty clamp

• GND Bus-bars: Pre‑drilled copper bars, both long and small

• Connectors & Lugs: High‑conductivity Cable Lux terminations

• Accessories: Soil enhancer compound, cable ties, labels, fixings

• Standards Compliance: Conforms to IEC standards and local grounding regulations

• Performance Features: Reliable earth fault protection and voltage equalization; durable copper and galvanized components for long service life; installation-friendly for server rooms, PAC systems, and power spaces; reduces the risk of equipment malfunction due to grounding instability

• Supplied Accessories: Earth rods and clamps, green‑insulated BYA bonding cable, flexible/PVC conduits and fittings, pre‑drilled GND bus‑bars, labeling kits, mounting hardware, test‑ready terminations

• Warranty & Service Support: Bidder shall provide 3 Years Comprehensive Service Support with Warranty including Free Spare Parts and Installation Assistance (Note: This reflects the tender’s bidder requirement specification, whereas the offered product column specifies OEM technical support and spare parts availability).

Conclusion

The Earthing Works service is specified for complete grounding installations. Its listed specifications cover earth rods, green-insulated 50 rm BYA copper cables, and pre-drilled bus-bars designed to achieve a resistance below 1 Ohm. Furthermore, the solution is intended for stated procurement requirements in Bangladesh.
