Eaton ELHNW Eluxa Indoor Horn Wall White Price in BD

Description

Product name: Eaton ELHNW Eluxa Indoor Horn Wall White Price in BD

Product Overview

The Eaton ELHNW is a white, wall-mount indoor horn from the Wheelock Eluxa line. It works on 12 or 24 VDC, so one model fits both voltages. In addition, it offers three horn patterns and two sound levels in one device. You change these settings in the field, and no tools are needed.

The horn has a low-profile, single-gang design. Moreover, a hinged mounting plate lets you pre-wire and pre-test the unit before you attach the horn. As a result, installation stays quick and clean.

Key Features

• 12 or 24 VDC operation, with 12 VDC/VFWR and 24 VDC/VFWR ranges
• Three horn patterns: Continuous, T3 and T3/T4, for fire and CO signaling
• Two sound levels: 86 dBA (low) and 91 dBA (high), anechoic
• Low current draw, from 20 mA to 28 mA
• Hinged mounting plate for pre-wiring and pre-testing
• Low-profile single-gang design with no visible mounting screws
• UL 464 and CAN/ULC-S525 listed

Technical Specifications

Brand: Eaton (Wheelock)
Model: ELHNW
Series: Eluxa
Type: Indoor horn
Mounting: Wall mount, single gang
Color: White
Housing: Plastic
Application: Indoor

Operating voltage: 12 VDC/VFWR (8.0 to 17.5 V) or 24 VDC/VFWR (16.0 to 33.0 V)
Horn patterns: Continuous, T3, T3/T4
Sound pressure (anechoic): 86 dBA (low), 91 dBA (high)
Current draw, 12 V range: 25 mA (high), 20 mA (low)
Current draw, 24 V range: 28 mA (high), 21 mA (low)
Wire connections: 12 to 18 AWG
Listing: UL 464, CAN/ULC-S525

Operating temperature: 32°F to 122°F (0°C to 50°C)
Dimensions: 4.75 in × 2.78 in × 1.3 in (121 × 71 × 33 mm)
Weight: 0.328 lb (149 g)
UPC: 786697009549

Applications

Use the ELHNW for indoor audible notification in fire alarm systems. Moreover, the T3/T4 pattern lets one horn cover both fire and CO signaling. Eaton lists the Eluxa line as UL/ULC compatible with FACPs approved for Wheelock RSS and Exceder LED3 products. However, always confirm panel compatibility before you install.

Conclusion

The Eaton ELHNW gives a 12/24 VDC wall-mount horn with three patterns and two sound levels. Its low current draw and hinged mounting plate keep installation simple. Therefore, it suits indoor fire alarm systems that need a compact single-gang horn.
