Product name: Edwards FX-270 Addressable Pull Station Price in Bangladesh
Brand: Kidde Commercial (also listed under the Edwards name)
Product Overview
The Edwards FX-270 is an intelligent (addressable) manual pull station with a single-action design and a die-cast metal housing. A single pull of the handle initiates the alarm. Each unit is identified on the fire alarm system by rotary address switches.
The FX-270 is a normally open dry-contact initiating device. It has an integral microprocessor, so the pull station shares data and status with the system. Kidde designed this range for small buildings.
Key Features
- Single-action operation: one pull initiates the alarm
- Die-cast metal body
- Rotary switch addressing
- Intelligent device with integral microprocessor
- Alarm latches at the station, manual reset required
- Status LEDs: flashing green for normal polling, flashing red for alarm
- Optional glass rod operation
- Meets ADA requirements for manual pull stations
- Twisted or shielded wire not required
- Designed for installation in ambient temperatures up to 120°F (49°C)
Technical Specifications
Brand: Edwards (Kidde Commercial)
Model: FX-270
Series: FX
Type: Intelligent manual pull station
Action: Single action
Material: Die-cast metal
Contact type: Normally open dry-contact initiating device with a factory-installed addressable single-input mini-module
Addressing: Rotary switches
Device address: 01 to 64 (64-point SLC), 01 to 125 (250-point control panel)
IDC maximum: 10 VDC at 350 µA
Communication line maximum: 20.6 V peak-to-peak
Standby current: 350 µA
Activated current: 500 µA
Wire size: 12 to 18 AWG (0.75 to 2.5 mm²)
Operating temperature: Up to 120°F (49°C) ambient
Compatible electrical boxes: 2-1/2 in. (64 mm) deep single gang box, or standard 4 in. square box 1-1/2 in. (38 mm) deep with single gang mud ring
Status LEDs: Flashing green (normal polling), flashing red (alarm)
Marking: Pull in Case of Fire
Color: Red
Compatibility: Designed for Kidde FX-64 and FX-1000 intelligent fire alarm systems
UPC: 793016036667
Applications
Manual alarm initiation in fire alarm systems that use Kidde intelligent panels, mainly in small buildings.
