Edwards SIGA-CC2A Dual Input Signal Module Price in Bangladesh

Description

Product Name: Edwards SIGA-CC2A Dual Input Signal Module Price in Bangladesh

Manufacturer: Edwards

Product Overview

The Edwards SIGA-CC2A operates as an analog addressable dual-input signal module. Moreover, it is engineered specifically for EDWARDS Signature Series systems. Furthermore, the unit connects a supervised Class A or Class B output circuit to two independent input risers.

In addition, upon command from the loop controller, the module connects its output circuit to either the Riser 1 or Riser 2 bus. Consequently, the output supports 24 VDC to power polarized audible and visible notification appliances. Similarly, it handles 25 VRMS or 70 VRMS to drive audio evacuation speakers and firefighter telephone risers. However, while the SIGA-CC2A handles output circuit connection, riser supervision must be provided by the host fire alarm control panel. Meanwhile, the loop controller assigns device addresses automatically. Therefore, it completely eliminates manual DIP switch setup.

Key Benefits

• Dual Riser Switching: Dynamically switches a single output circuit between two input risers. Thus, it seamlessly manages 24 VDC signal power or 25 VRMS / 70 VRMS audio.

• Flexible Circuit Support: Supports Class A or Class B notification appliance circuits (NACs). Additionally, it works with audio evacuation speakers and 3-state or 4-state firefighter telephone risers.

• Panel-Provided Riser Supervision: Designed for integration into systems where riser supervision is managed by the host fire alarm panel.

• Automatic Electronic Addressing: Receives operational addresses and personality codes directly from the Signature Loop Controller. Hence, manual address switches are not required.

Key Features & Technologies

• Signature Series Compatibility: Operates smoothly as part of EDWARDS Signature Series systems.

• Signal & Audio Riser Support: Handles 24 VDC notification circuits. Furthermore, it supports 25 VRMS or 70 VRMS audio evacuation channels and firefighter telephone lines.

• Personality Code Configuration: Configures operational modes via controller-downloaded personality codes. Thus, it enables dual-input riser selection or telephone selector functions.

• Loop Circuit Mapping: Transmits information to the loop controller regarding circuit locations relative to other Signature devices.

• Serial Number Tracking: Includes removable serial number labels. As a result, it simplifies project logging and database tracking.

Technical Specifications Overview

• Brand: Edwards / EST

• Model: SIGA-CC2A

• Product Type: Dual Input Signal Module (Standard Mount, Class A / Class B Output)

• Nominal Operating Voltage: 20 VDC

• Operating Current: 310 µA Standby, 135 µA Alarm

• Output Ratings: 24 VDC at 2 A; 25 VAC audio  at 50 W; 70 VRMS audio at 35 W

• End-of-Line Resistor: 47 kΩ

• Ground Fault Impedance: 10 kΩ

• Addresses Required: 2 Device Addresses

• Wire Size: Terminals suited for #12 to #18 AWG (2.5 mm² to 0.75 mm²) wire

• Operating Temperature: 0°C to 49°C (32°F to 120°F)

• Humidity: 0%–93% RH, non-condensing at 32°C (90°F)

• Mounting Box: Fits North American 2-1/2 inch (64 mm) deep 2-gang electrical boxes. Alternatively, it fits 1-1/2 inch (38 mm) deep 4-inch square boxes with 2-gang covers and SIGA-MP mounting plates.

Conclusion

The Edwards SIGA-CC2A Dual Input Signal Module provides dual-riser output switching for EDWARDS Signature Series fire alarm platforms. Moreover, its support for 24 VDC notification power, 25 VRMS / 70 VRMS audio evacuation, and Class A or Class B output operations facilitates signal distribution across commercial installations.
