Description
Product Name: Heavy Duty Aluminium Raised Access Floor Series in Bangladesh
Manufacturer: Atflor
Product Overview
The Heavy Duty Aluminium Raised Access Floor series (Model Nos. 1000/Series, 1200/Series, 1500/Series, and 1000 Series Grid type) is engineered for a range of technical environments requiring high load-bearing capabilities. Built from high-grade die-casting aluminum (ADC12), it features precise dimensional tolerances, versatile open ratio choices, and specialized electrostatic discharge (ESD) surface performance for high-demand technical and server room infrastructure.
Key Features
-
Reliable Load Performance: Available in 1000, 1200, 1500, and 1000 Grid series configurations, delivering dependable concentrated, ultimate, and uniform load capacities.
-
Flexible Ventilation Options: Designed with open ratio choices ranging from 0% (solid), 17%, 25%, up to 50% for the grid type to support various airflow management and cooling requirements.
-
Surface Materials & Finishes: Available with HPL and PVC surface materials with fireproof performance, along with optional SUS304 stainless steel finishes and epoxy surface treatments.
-
Electrostatic Discharge (ESD) Performance: Features electrostatically conductive PVC and epoxy treatments with specified electrical resistance ranges of $10^4 – 10^6$ $\Omega$, $10^6 – 10^9$ $\Omega$, and less than $1 \times 10^9$ $\Omega$ for static-control applications.
-
Precision Manufacturing: Manufactured using die-casting aluminum (ADC12) with strict length, width, thickness, planeness, and diagonal tolerances for seamless installation.
Characteristic Specifications
-
Series Options: Model 1000/Series, 1200/Series, 1500/Series, and 1000 Series Grid type configurations.
-
Material Composition: Die-casting aluminum base material (ADC12) ensuring lightweight yet robust structural integrity.
-
Tolerance Standards: High precision with strict manufacturing thresholds for length, width, thickness, planeness, and diagonal alignment.
-
Application Scope: Suited for technical environments, computer rooms, and telecommunication spaces requiring structural stability and static-control flooring infrastructure.
Technical Specification
| Component / Parameter | Specification Details |
| Product Series | Heavy Duty Aluminium Raised Access Floor (1000, 1200, 1500 & 1000 Grid Series) |
| Concentrated Load (kgf/6.45cm² with $\le 2.0mm$) | 1000 (1000 Series), 1200 (1200 Series), 1500 (1500 Series), 1000 (1000 Grid Series) |
| Ultimate Load (kgf/6.45cm² with $\le 2.0mm$) | 2000 (1000 Series), 2400 (1200 Series), 3000 (1500 Series), 2000 (1000 Grid Series) |
| Uniform Load (kgf/m² with $\le 1.0mm$) | 3000 (1000 Series), 3600 (1200 Series), 4500 (1500 Series), 3000 (1000 Grid Series) |
| Open Ratio | 0%, 17%, 25% (1000, 1200 & 1500 Series); 50% (1000 Grid Series) |
| Surface Material | HPL, PVC with fireproof performance; SUS304 optional; Epoxy surface treatment |
| ESD Performance | Electrostatic conductive PVC and epoxy treatments: $10^4 – 10^6$ $\Omega$, $10^6 – 10^9$ $\Omega$, and $<1 \times 10^9$ $\Omega$ |
| Base Material | Die casting Aluminium, ADC12 |
| Dimensional Tolerances | Length/width: $600^{+0.00}_{-0.20} mm$; Thickness: $\pm0.10 mm$; Planeness: $\pm0.20 mm$; Diagonal: Max. $0.50 mm$ |
Note: Specifications follow the manufacturer’s supplied information. Users should verify specific load ratings, dimensional configurations, and applicable standards with the original manufacturer datasheet.
Conclusion
The Heavy Duty Aluminium Raised Access Floor combines die-cast ADC12 aluminum construction with balanced load-bearing capacities across the 1000, 1200, 1500, and 1000 Grid series. Featuring multiple open-ratio configurations, precise manufacturing tolerances, and ESD-conductive surface options, it provides a dependable raised-floor solution for high-demand technical, computer room, and telecommunication environments.
Contact Us
For pricing inquiries, system design, and stock availability in Bangladesh, get in touch with our team:
-
Phone: +8801737118246
-
Email: [email protected]
