Mirtone GSA-IPHS Intelligent 4D Multi Sensor Detector Price Bangladesh

Description

Product Name: Mirtone GSA-IPHS Intelligent 4D Multi Sensor Detector Price Bangladesh

Brand: Mirtone / Vigilant

Model: GSA-IPHS

Product Overview

The Mirtone GSA-IPHS operates as an intelligent 4D multi-sensor detector combining three physical sensing elements—ionization, photoelectric, and thermal—analyzed over time as a fourth element. Designed for open-area fire detection on compatible Signature Series loop controllers, it processes environmental data using onboard dynamic signal filters to identify both fast-flaming and smoldering fires while filtering out transient non-fire conditions.

Furthermore, the GSA-IPHS features onboard microprocessor intelligence, electronic addressing, and non-volatile memory that stores serial number and device history details. It mounts on standard, relay, fault isolator, or sounder Signature Series bases across commercial, educational, and institutional life safety installations.

Key Benefits

• 4D Multi-Sensor Processing: Combines ionization (fast flaming), photoelectric (smoldering smoke), and thermal sensing across dynamic algorithms to analyze ambient fire conditions.

• Integral Microprocessor Intelligence: Onboard microprocessor analyzes sensor input and evaluates alarm criteria independently at the detector head.

• Dynamic Signal Filtering: Utilizes digital filters to differentiate between environmental noise patterns and actual fire signals.

• Electronic Addressing: Transmits precise device mapping and location data directly to the loop controller.

Key Features & Compatibility

• Triple Physical Sensing Elements: Integrates a unipolar ionization chamber, light-scattering photoelectric sensor, and fixed-temperature thermal sensor.

• Twin Status LED Indicators: Includes twin LEDs visible from 360 degrees—flashing green for normal polling and flashing/steady red for alarm state.

• Selectable Sensitivity Window: Supports panel-selectable sensitivity settings ranging from 1.0%/ft to 3.5%/ft obscuration.

• Compatible Mounting Bases: Fits Signature Series mounting bases including standard (GSA-SB / GSA-SB4), relay (GSA-RB), isolator (GSA-IB), and sounder bases.

Technical Specifications Overview

• Brand: Mirtone / Vigilant

• Model: GSA-IPHS

• Product Type: Intelligent 4D Multi-Sensor Detector (Ionization / Photoelectric / Heat)

• Operating Voltage Range: 15.2 VDC to 19.95 VDC (19 VDC nominal)

• Quiescent Current Draw: 45 µA @ 19 VDC

• Alarm Current Draw: 45 µA @ 19 VDC (18 mA in emergency stand-alone mode)

• Sensors Integrated: Unipolar Ionization, Optical Photoelectric, Thermal

• Sensitivity Range: 0.67% to 3.70% obscuration/ft

• Heat Sensor Rating: Alarms at 65°F (35°C) rise above ambient

• Air Velocity Rating: 0 to 500 ft/min (0 to 2.53 m/s)

• Operating Temperature Range: 32°F to 100°F (0°C to 38°C)

• Operating Humidity Range: 0% to 93% RH (non-condensing)

• Construction & Finish: High-impact engineering polymer, White

Conclusion

The Mirtone GSA-IPHS Intelligent 4D Multi-Sensor Detector provides multi-criteria fire detection for compatible Signature Series loops. Its combination of ionization, photoelectric, and thermal sensing elements, 19 VDC loop operation, digital signal filtering, and electronic addressing support structured fire protection across commercial and industrial facilities.
