Potter OSYSU-1 OS&Y Valve Supervisory Switch Price in Bangladesh

Description

Product Name: Potter OSYSU-1 OS&Y Valve Supervisory Switch Price in Bangladesh

Brand: Potter Electric Signal Company

Product Overview

The Potter OSYSU-1 is an Outside Screw and Yoke (OS&Y) valve supervisory switch. It monitors the open position of an OS&Y gate valve in a fire sprinkler system. The OSYSU-1 has one set of SPDT (Form C) contacts. It is wired to the supervisory circuit of a fire alarm control panel.

The switch mounts on most OS&Y valves from 2″ to 12″ (50 mm to 300 mm), and on some valves as small as 1/2″ (12.5 mm). A three-position switch detects both tampering and valve closure.

Key Features

• Monitors the open position of OS&Y gate valves
• One set of SPDT (Form C) contacts
• Three-position switch detects tampering and valve closure
• Visual switch indicators show the switch status
• Fits 2″ to 12″ (50 to 300 mm) OS&Y valves, and some smaller valves
• NEMA 4X and 6P enclosure, for indoor or outdoor use in any mounting position
• Two conduit entrances
• Cover held by tamper-resistant screws, special tool furnished with each unit
• Micro-adjust feature and adjustable-length trip rod for fine positioning
• Knurled mounting bracket to prevent slipping on the valve yoke
• Optional field-installable cover tamper switch kit
• Normal service life of 10 to 15 years

Technical Specifications

Brand: Potter Electric Signal Company, LLC
Model: OSYSU-1
Series: OSYSU
Stock number: 1010102
Type: OS&Y valve supervisory switch (single switch)
Contacts: One set SPDT (Form C)
Contact rating: 10 A at 125/250 VAC, 2 A at 30 VDC
Valve size: 2″ to 12″ (50 to 300 mm), some valves down to 1/2″ (12.5 mm)
Enclosure rating: NEMA 4X and 6P
Conduit entrances: Two
Operating temperature: Minus 40°F to 140°F (minus 40°C to 60°C)
Dimensions: 6.19″ L × 2.25″ W × 5.88″ H (15.7 × 5.7 × 14.6 cm)
Approvals: UL and cUL listed, FM approved, CE marked
Package contents: Switch and special tool
Optional accessory: Cover tamper switch kit, stock number 0090200

Applications

The OSYSU-1 is used on OS&Y gate valves that control water flow to any part of a fire sprinkler system. The datasheet lists service use in automatic sprinkler systems (NFPA 13) and one or two family dwelling systems (NFPA 13D).
