Safeway AT4233A Mini X-Ray Baggage Scanner Price in Bangladesh | Compact Security Solutions

Description

Product Name: Safeway AT4233A Mini X-Ray Baggage Scanner Price in Bangladesh | Compact Security Solutions

Manufacturer: Safeway System

Product Description

The Safeway AT4233A Mini X-Ray Baggage Scanner is a compact security inspection system designed for screening small laptops, suitcases, handbags, parcels, and mailboxes. Engineered with a dedicated 42 cm x 34 cm tunnel size, it features an all-digital signal transmission and processing architecture to deliver high-definition images with strong anti-interference capability. Powered by an embedded Linux operating system and multi-core ARM architecture, the AT4233A offers low power consumption, energy efficiency, and reliable continuous operation for shopping malls, subways, schools, factories, and mobile vehicle-mounted installations across Bangladesh.

Key Features

• Compact Mini Design: Features the smallest footprint and tunnel size (42 cm x 34 cm) in the X-ray baggage scanner family, making it ideal for restricted spaces and mobile vehicle mounting.

• All-Digital Processing Architecture: Engineered with an all-digital signal transmission and processing architecture, it delivers high-definition images with strong anti-interference capability.

• Embedded Linux & ARM System: Powered by an embedded Linux operating system and multi-core ARM CPU for a simple architecture, low power consumption, and real-time status monitoring.

• Long-Term Reliability: Designed for long-term reliability, the system has undergone high-low temperature, humidity, and vibration testing to support continuous operation.

• Comprehensive Image Processing: Offers advanced diagnostic tools including color/black and white, high/low penetration, super increase, inverse color, edge enhancement, and suspicious object marking.

• Robust Self-Diagnosis & POST: Features automated power-on self-testing with fault detection displays for emergency stops, side panel status, and hardware acquisition performance.

• TIP (Threat Image Projection) Management: Supports customizable insertion of fictional threat items to monitor operator vigilance and generate performance evaluation reports.

• User Authority Management: Multi-level user login security with customizable operation permissions, detailed activity logs, and bilingual system support.

Technical Specifications

• Brand: Safeway System

• Model: AT4233A

• Scanner Type: Mini X-Ray Baggage & Parcel Inspection System

• Tunnel Size: 420 mm (Width) x 340 mm (Height)

• Inspection Technology: Single-Energy All-Digital X-Ray Imaging (1 Generator)

• X-Ray Generator Anode Voltage: 80 kV (Sealed oil cooling)

• Wire Resolution: 40 AWG

• Penetration Resolution: 32 AWG

• Spatial Resolution: Vertical 1.0 mm, Horizontal 1.0 mm

• Steel Penetration: 8 mm

• Conveyor Speed: Around 0.2 m/s

• Conveyor Maximum Load: 100 kg

• Single Inspection Dose: ≤ 3.5 µSv (µGy)

• Leakage Dose: < 1 µSv/h (µGy/h)

• Leakage Current: ≤ 5.0 mA

• Film Safety: Compliant with ASA/ISO 1600 Film Safety Standards

• Noise Level: No more than 60 dB

• Maximum Power Consumption: 0.5 kW

• Operating System: Linux (1GB RAM, 8GB Storage)

• Display Monitor: 21.5-inch LCD monitor with a resolution of 1920 x 1080

• Working Power: AC 220V (+10% to -15%), 50 Hz ±3 Hz

• Unit Weight: 260 kg

• Working Environment: 5°C to 40°C, 0% to 90% relative humidity

Applications

• Shopping Malls and Retail Complexes

• Subway and Metro Stations

• Schools, Universities, and Educational Institutions

• Industrial Factories and Manufacturing Plants

• Mobile Vehicle-Mounted Security Units

• Government Agencies and Offices

• Courts and Detention Centers

• Hotels and Entertainment Venues

Conclusion

The Safeway AT4233A Mini X-Ray Baggage Scanner combines an ultra-compact footprint, all-digital signal processing, and robust Linux-based software management to deliver reliable security screening for small items. Designed for space-constrained and mobile checkpoints, it supports efficient security inspection and reliable parcel screening across commercial and public facilities.
