Safeway AT6040A X-Ray Baggage Scanner Buy Online BD | Linux-Based Parcel & Luggage Inspection Solutions

Description

Product Name: Safeway AT6040A X-Ray Baggage Scanner Buy Online BD | Linux-Based Parcel & Luggage Inspection Solutions

Manufacturer: Safeway System

Product Description

The Safeway AT6040A X-Ray Baggage Scanner is an advanced, all-digital security inspection system powered by an embedded Linux operating system and a multi-core ARM CPU architecture. Featuring comprehensive digital signal processing, high penetration, and exceptional reliability tested for over 10,000 hours of continuous operation, it provides non-destructive inspection for briefcases, parcels, hand luggage, and express mail. Widely deployed across hotels, shopping malls, schools, government buildings, and transport terminals in Bangladesh, the AT6040A delivers energy-efficient, low-power, and high-definition parcel screening.

Key Features

• Embedded Linux & ARM Architecture: Built on a stable multi-core ARM processor and Linux OS, offering low power consumption, energy efficiency, and real-time status monitoring.

• All-Digital Processing Chain: First all-digital security inspection machine design in its class, transmitting and processing signals digitally from detection to display for superior anti-interference and image definition.

• Extreme Reliability: Certified through rigorous high-low temperature, damp heat, and vibration experiments to guarantee continuous operation for more than 10,000 hours without failure.

• Advanced Image Enhancement: Features color/B&W, local enhancement, high/low penetration super enhancement, negative, brightening, darkening, gray-level scan, 1-16x continuous zoom, and magnifying glass tools.

• Comprehensive System Management: Includes multi-level user authority management, Threat Image Projection (TIP) management, self-diagnostics, multi-format image exporting, operator training functions, and remote operation support.

Technical Specifications

• Brand: Safeway System

• Model: AT6040A

• Scanner Type: Introscope X-Ray Baggage & Parcel Scanner

• Tunnel Size: 600 mm (Width) × 400 mm (Height)

• X-Ray Generator: 80 kV, oil cooling, bottom-to-top beam direction

• Wire Resolution: Typical AWG 40

• Penetration Resolution: Typical AWG 32

• Spatial Resolution: Vertical 1.0 mm, Horizontal 1.0 mm

• Conveyor Speed: 0.2 m/s

• Conveyor Maximum Load: 100 kg

• Single Inspection Dose: ≤ 3.5 µSv (µGy)

• Boundary Leakage Dose: ≤ 0.5 µSv/h (µGy/h)

• Noise Level: < 60 dB

• Maximum Power Consumption: 0.5 kW

• Computer & Hardware: Multi-core ARM CPU, 500G Hard Drive, 1G Storage memory

• Display Monitor: 21.5-inch LED screen with 1280 × 1024 pixel resolution

• Operating System: Embedded LINUX

• Working Power: AC 220V (±10% to -15%), 50 ±3 Hz

• Unit Weight: 260 kg

• Working Environment: 5°C to 40°C, 0% to 90% relative humidity

Applications

• Hotels, Shopping Malls, and Entertainment Venues

• Schools, Universities, and Hospitals

• Government Agencies, Courts, and Embassies

• Logistics Hubs, Express Mail Sorting, and Transport Terminals

• Prisons, Industrial Factories, and Gymnasiums

Conclusion

The Safeway AT6040A X-Ray Baggage Scanner combines an energy-efficient Linux ARM architecture, robust all-digital signal processing, and proven 10,000-hour reliability to deliver cost-effective and dependable security screening. Engineered for commercial and institutional checkpoints, it ensures precise threat detection and seamless operational longevity across facilities in Bangladesh.
