Safeway ZA6550 X-Ray Baggage Scanner Price in BD | Multi-Language Security Solutions

Description

Product Name: Safeway ZA6550 X-Ray Baggage Scanner Price in BD | Multi-Language Security Solutions

Manufacturer: Safeway System

Product Description

The Safeway ZA6550 X-Ray Baggage Scanner is an advanced multi-language security inspection system designed for screening small baggage, parcels, express mail, hand luggage, and suitcases without unpacking. Sharing identical technical specifications with the TH6550 model under a distinct housing shell, it operates on a robust Linux operating system powered by an ARM CPU with a 500GB hard drive and 1GB storage memory. It integrates a high-performance 140 kV X-ray generator and sophisticated digital signal processing tools to deliver exceptional penetration and precise material discrimination. Widely utilized across government agencies, transport hubs, logistics facilities, courts, and corporate checkpoints in Bangladesh, the ZA6550 guarantees reliable high-capacity baggage screening and dependable threat detection.

Key Features

• Optimal Security Tunnel: Features an efficient tunnel configuration specifically tailored for inspecting handbags, suitcases, parcels, and hand luggage.

• Advanced Image Processing: Supports color/black & white imaging, negative display, high/low penetration enhancement, organic/inorganic stripping, general enhancement, and pseudo-color adjustments.

• Substantial Image Storage: Automatically stores up to 10,000 inspection images with support for file querying, viewing, exporting, and recalling the 30 preceding images.

• Comprehensive Diagnostic Tools: Includes automated power-on self-testing (POST), real-time curve monitoring, component troubleshooting, and probe settings for dead pixel management.

• TIP (Threat Image Projection) Management: Supports customizable insertion of virtual threat items to evaluate operator vigilance and generate performance evaluation reports.

• User Authority Management: Multi-level user login controls with customizable permission levels, detailed activity logging, and bilingual system support.

Technical Specifications

• Brand: Safeway System

• Model: ZA6550 (OEM version sharing specs with TH6550)

• Scanner Type: Compact X-Ray Baggage & Parcel Inspection System

• Inspection Technology: Single-View Bottom-to-Top X-Ray Imaging (1 Generator)

• X-Ray Generator Anode Voltage: 140 kV (Sealed oil cooling)

• Wire Resolution: Typical AWG 40

• Penetration Resolution: Typical AWG 32

• Spatial Resolution: Vertical 1.0 mm, Horizontal 1.0 mm

• Steel Penetration: Typical 30 mm

• Conveyor Speed: 0.2 m/s

• Conveyor Max Load: 180 kg

• Single Inspection Dose: ≤ 2.5 µSv (µGy)

• Boundary Leakage Dose: ≤ 0.5 µSv/h (µGy/h)

• Film Safety: Compliant with ASA/ISO 1600 Film Safety Standards

• Noise Level: Less than 60 dB

• Maximum Power Consumption: 0.5 kW

• Operating System: Linux (ARM CPU, 500GB HDD, 1GB RAM)

• Display Monitor: 21.5-inch LED screen with a resolution of 1280 x 1024 pixels

• Working Power: AC 220V (±10% to -15%), 50 ±3 Hz

• Unit Weight: 450 kg

• Working Environment: 5°C to 40°C, 0% to 90% relative humidity

Applications

• Government Agencies and Public Security Checkpoints

• Transportation Hubs, Subways, and Railway Stations

• Logistics Facilities and Express Courier Centers

• Courts, Procuratorates, and Correctional Prisons

• Embassies, Schools, Hospitals, and Universities

• Shopping Malls, Exhibition Halls, and Entertainment Venues

Conclusion

The Safeway ZA6550 X-Ray Baggage Scanner combines a robust inspection platform, reliable 140kV X-ray imaging, and flexible Linux-based management to deliver professional-grade security screening. Engineered for demanding access control points and high-traffic checkpoints, it guarantees efficient operations and uncompromised safety compliance across commercial and institutional facilities in Bangladesh.
