Safeway ZA8065A X-Ray Baggage Scanner Price in Bangladesh | Security Inspection System

Description

Product Name: Safeway ZA8065A X-Ray Baggage Scanner Price in Bangladesh | Security Inspection System

Manufacturer: Safeway System

Product Description

The Safeway ZA8065A OEM X-Ray Baggage Scanner is an advanced security inspection system featuring an 80×65 cm tunnel size, designed sharing identical high-performance specifications with the AT8065A model within a custom housing shell. Powered by an embedded Linux operating system and a multi-core ARM CPU with digital signal processing, it offers non-destructive screening for briefcases, parcels, express mail, and hand luggage. Suitable for transit hubs, hotels, government checkpoints, and religious venues, the ZA8065A ensures continuous reliability, high-definition imaging, and robust threat detection capabilities across Bangladesh.

Key Features

• Embedded Linux Architecture: Operates on a stable, multi-core ARM CPU platform with digital signal processing for low power consumption and strong anti-interference performance.

• Continuous High-Reliability Operation: Certified through rigorous environmental testing to run continuously for over 10,000 hours without failure.

• Comprehensive Image Processing: Provides multiple enhancement modes including color/black-and-white, local enhancement, high/low penetration boost, negative view, and 1–16 times continuous zoom.

• Extensive Management & TIP Tools: Features automated power-on self-tests, multi-level user management, Threat Image Projection (TIP) management, and multi-format image export options.

• High-Capacity Conveyor System: Equipped with a durable 200 kg maximum load conveyor belt operating at 0.2 m/s for efficient passenger and parcel screening.

Technical Specifications

• Brand: Safeway System

• Model: ZA8065A (OEM version of AT8065A)

• Scanner Type: X-Ray Baggage & Parcel Inspection System

• Tunnel Size: 80 cm (Width) × 65 cm (Height)

• X-Ray Generator Anode Voltage: 100 kV (Top-to-bottom, oil cooling)

• Wire Resolution: Typical 36 AWG

• Penetration Resolution: Typical 24 AWG

• Spatial Resolution: Vertical 2.0 mm, Horizontal 2.0 mm

• Steel Penetration: Typical 12 mm

• Conveyor Speed: 0.2 m/s

• Conveyor Max Load: 200 kg

• Single Inspection Dose: ≤ 3.0 µSv (µGy)

• Boundary Leakage Dose: ≤ 0.5 µSv/h (µGy/h)

• Noise Level: Less than 60 dB

• Maximum Power Consumption: 1.0 kW

• Computer Configuration: ARM CPU with 500G Hard Drive and 1G System Memory (Linux Operating System)

• Display Monitor: 17-inch LED screen with 1280 × 1024 resolution

• Console & Keyboard: Single screen console with specialized security keyboard

• Working Power: AC 220V (+10% to -15%), 50 Hz ±3 Hz

• Unit Weight: 600 kg

• Working Environment: 5°C to 40°C, 0% to 90% relative humidity

• Film Safety: Guarantee ASA/ISO 1600 standard film

Applications

• Subway and Bus Stations

• Hotel Entrances and Hospitality Venues

• Churches and Religious Centers

• Customs Facilities and Checkpoints

• Government Agencies and Public Buildings

• Logistics Hubs and Express Delivery Warehouses

Conclusion

The Safeway ZA8065A X-Ray Baggage Scanner delivers dependable, all-digital security screening through its stable Linux-ARM architecture and reliable 100 kV X-ray generation. Built for high-traffic public access and checkpoint environments, it guarantees optimal throughput, precision threat identification, and long-term operational durability.
