Siemens AS-75-CR-WP red weatherproof ceiling mount horn strobe with FIRE lettering

Siemens AS-75-CR-WP Weatherproof Horn Strobe Price in BD

0.00৳

Categories: , Tags: , , , , , , , , ,

Description

Product name: Siemens AS-75-CR-WP Weatherproof Horn Strobe Price in BD

Product Overview

The Siemens AS-75-CR-WP is a red, ceiling-mount weatherproof horn strobe from the AS series. It combines a selectable horn with a xenon strobe in one two-wire device. In addition, Siemens lists it for outdoor use under UL 1638 and for indoor use under UL 1971. As a result, one model covers indoor and outdoor ceiling locations.

You choose a continuous or Code 3 tone in the field. Moreover, you pick one of three sound levels. Note that the “75” in the model name is not a 75 cd rating. Siemens rates this model at 115 cd for outdoor use and at 30 cd, with 180 cd on axis, for indoor use.

Key Features

  • Red ceiling-mount weatherproof horn strobe with FIRE lettering
  • Strobe ratings: 115 cd (UL 1638, outdoor) and 30 cd, 180 cd on axis (UL 1971, indoor)
  • Xenon flashtube in a Lexan lens, one flash per second, low-current design
  • Selectable continuous or Code 3 tone with three sound levels
  • Sound output of 90, 95 and 99 dBA anechoic
  • Sync with Siemens DSC modules, compatible FACPs, and PAD-3 and PAD-4 NAC extenders
  • Horn can be silenced while the strobe stays active, with Siemens sync
  • Screw terminals for 12 to 18 AWG wire
  • UL, ULC, FM and CSFM listed or approved

Technical Specifications

Brand: Siemens
Model: AS-75-CR-WP
Part number: 500-636015
Series: AS
Type: Weatherproof horn strobe, ceiling mount
Color: Red
Lettering: FIRE
Lens: Clear
Application: Indoor and outdoor

Strobe rating, outdoor (UL 1638): 115 cd at minus 40°C
Strobe rating, indoor (UL 1971): 30 cd, 180 cd on axis
Light source: Xenon flashtube in a Lexan lens
Flash rate: 1 flash per second
Operating voltage: 16.0 to 33.0 VDC or VRMS (FWR)
Maximum RMS current, high dBA setting: 0.178 A (DC), 0.249 A (FWR)
Maximum RMS current, medium dBA setting: 0.164 A (DC), 0.239 A (FWR)
Maximum RMS current, low dBA setting: 0.159 A (DC), 0.233 A (FWR)
Synchronization: Siemens DSC modules; Siemens 50-point, 252-point and 504-point FACPs; FireFinder XLS and MXL FACPs; PAD-3 and PAD-4 NAC extenders

Horn tone: Continuous or Temporal (Code 3)
Sound settings: Three field-selectable levels
Sound output: 90, 95 and 99 dBA anechoic
Terminals: In/out screw terminals, 12 to 18 AWG
Listings: UL 464, UL 1638, UL 1971
Approvals: UL, ULC, FM, CSFM
Compliance: ADA, NFPA, UFC, ANSI

Applications

Use the AS-75-CR-WP for ceiling-mount fire alarm notification where a weatherproof horn strobe is needed. However, check the candela rating against your project design, because the model is rated 115 cd outdoors and 30/180 cd indoors. Also, confirm panel and NAC compatibility before you install.

Conclusion

The Siemens AS-75-CR-WP gives a weatherproof horn and strobe in one ceiling-mount unit. Its selectable tones, three sound levels and sync options suit varied projects. Therefore, it fits indoor and outdoor fire alarm systems that need a red, ceiling-mount appliance.
