Product Price: System Sensor 2251-COPTIR Multi-Criteria Smoke Sensor Price in BD
Product Overview
The System Sensor 2251-COPTIR is an intelligent addressable multi-criteria fire detector. It combines four separate sensing elements—photoelectric smoke, electrochemical carbon monoxide (CO), infrared (IR), and thermal sensing—into a single unit. By evaluating multiple fire signatures simultaneously through onboard algorithms, it is designed to improve real-fire response times while enhancing resistance to nuisance alarms.
Specifications & Features
-
Brand & Model: System Sensor 2251-COPTIR
-
Product Type: Intelligent Addressable Multi-Criteria Fire Detector
-
4-Sensor Technology: Integrates photoelectric chamber, electrochemical CO cell, infrared (IR) sensor, and thermal element.
-
Thermal Rating: Fixed-temperature thermal detection at $135^\circ\text{F}$ ($57^\circ\text{C}$).
-
Operating Voltage & Current: Operates on 15–32 VDC with a maximum standby current of 300 $\mu\text{A}$ at 24 VDC.
-
CO Cell Lifespan: Electrochemical CO cell has an expected operating lifespan of approximately 6 years with automatic end-of-life signaling.
-
Addressing & Status: Features rotary decade address switches and twin LEDs providing $360^\circ$ status visibility.
-
Mounting Base Compatibility: Compatible with standard System Sensor bases including B501, B210LP, and B200SR sounder base.
-
Dimensions & Weight: Measures 2.7 in (H) installed in B210LP/B501 base, with a diameter of 6.0 in (B210LP) or 4.0 in (B501); shipping weight is approximately 4.6 oz.
Conclusion
The System Sensor 2251-COPTIR is an addressable 4-sensor multi-criteria detector engineered for comprehensive fire sensing in demanding commercial and industrial applications.
Contact Us
For pricing inquiries and orders for the System Sensor 2251-COPTIR Sensor in Bangladesh, get in touch with our team:
-
Phone: +8801737118246
-
Email: [email protected]
