Vertiv™ Liebert® DS Direct Expansion Cooling System | Flexible DX Cooling for Data Centers in Bangladesh

Description

Product Name: Vertiv™ Liebert® DS Direct Expansion Cooling System | Flexible DX Cooling for Data Centers in Bangladesh

Manufacturer: Vertiv

Product Overview

As the world’s most flexible and reliable direct expansion data center cooling system, the Liebert DS Direct Expansion Cooling System improves data center efficiency and protection. The system uses the industry’s most advanced thermal controls and features a modular design, multiple compressor options and easy service access.

Liebert DS data center cooling system provides efficient, precise, reliable control of room temperature, humidity and airflow. The flexible Liebert DS offers high energy efficiency, user-friendly Liebert iCOM unit controls, a modular frame, front service access, and multiple compressor and fan options. Liebert DS is offered in downflow models from 35-105kW (10-30 tons) capacities and upflow models in 35-105kW (10-30 tons) capacities. Cooling types include air, water/glycol and GLYCOOL™.

Key Benefits

• Highly Energy Efficient: Exceeds the most stringent government efficiency requirements with NEMA premium efficiency motors.

• Variable Speed EC Fans: Offers energy efficient variable speed EC fans on downflow configurations.

• Flexible Cooling Capacity: Provides variable capacity cooling via variable capacity compressors.

• Easy Service Access: Requires only front access for service.

• Modular Construction: Installs easily due to modular frame construction.

• Advanced Monitoring: Brings high-level supervision with Liebert iCOM controls, allowing networking of multiple cooling units.

• Variable Capacity Control: Designed for ultimate control and reliability.

• High Reliability & Redundancy: Features redundancy through dual refrigeration circuits.

Technical Specifications

• Brand: Vertiv

• Model Range: Liebert® DS Direct Expansion Cooling System

• Total Nominal Capacity: 35 kW to 105 kW (10-30 tons)

• Airflow Configuration: Downflow and Upflow models

• Cooling Types: Air, water/glycol, and GLYCOOL™

• Control Platform: Liebert iCOM Unit Controls

Model Specifications

• Liebert DS, DS035A, 35kW

  • Total Nominal Capacity: 119.4 kBtuh [35 kW]

  • Net Sensible Capacity: 136.4 kBtuh [40 kW]

  • Nominal Airflow: 5,200 CFM

  • Dimensions (Height x Width x Depth): 76 in x 73 in x 35 in

  • Weight: 1,920 lbs

• Liebert DS, DS042A, 42kW

  • Total Nominal Capacity: 143.3 kBtuh [42 kW]

  • Net Sensible Capacity: 154.7 kBtuh [45.3 kW]

  • Nominal Airflow: 6,200 CFM

  • Dimensions (Height x Width x Depth): 76 in x 73 in x 35 in

  • Weight: 1,470 lbs

• Liebert DS, DS053A, 53kW

  • Total Nominal Capacity: 143.3 kBtuh [53 kW]

  • Net Sensible Capacity: 215.7 kBtuh [63.2 kW]

  • Nominal Airflow: 8,000 CFM

  • Dimensions (Height x Width x Depth): 76 in x 98 in x 35 in

  • Weight: 1,920 lbs

• Liebert DS, DS070A, 70kW

  • Total Nominal Capacity: 238.8 kBtuh [70 kW]

  • Net Sensible Capacity: 255.6 kBtuh [74.9 kW]

  • Nominal Airflow: 9,600 CFM

  • Dimensions (Height x Width x Depth): 76 in x 98 in x 35 in

  • Weight: 1,970 lbs

• Liebert DS, DS077A, 77kW

  • Total Nominal Capacity: 262.7 kBtuh [77 kW]

  • Net Sensible Capacity: 275.1 kBtuh [80.6 kW]

  • Nominal Airflow: 11,000 CFM

  • Dimensions (Height x Width x Depth): 76 in x 98 in x 35 in

  • Weight: 2,020 lbs

• Liebert DS, DS105A, 105kW

  • Total Nominal Capacity: 358.2 kBtuh [105 kW]

  • Net Sensible Capacity: 338.3 kBtuh [99.1 kW]

  • Nominal Airflow: 13,700 CFM

  • Dimensions (Height x Width x Depth): 76 in x 132 in x 35 in

  • Weight: 2,660 lbs

Conclusion

As the world’s most flexible and reliable direct expansion data center cooling system, the Liebert DS Direct Expansion Cooling System improves data center efficiency and protection. It offers data center operators in Bangladesh an efficient, modular direct expansion cooling architecture with capacities ranging from 35 kW to 105 kW.
