ABB AF460-30-11-70 Best Price in Bangladesh

Description

Product Name: ABB AF460-30-11-70 Best Price in Bangladesh

Manufacturer: ABB

Product Overview

The ABB AF460-30-11-70 is a 3-pole block magnetic contactor engineered for heavy-duty industrial power switching and motor control applications. Designed in accordance with IEC 60947-4-1 standards, this high-performance unit handles motor control up to 250 kW / 400 V AC (AC-3) or 400 hp / 480 V UL, and switches power circuits up to 700 A under AC-1 utilization category. Equipped with advanced AF technology, it features a wide control voltage range to manage voltage variations and ensure reliable operation in unstable networks.

Key Features

• AF Technology: Features a wide control voltage range (100–250 V AC/DC) that dampens voltage fluctuations and reduces panel energy consumption.

• Pre-mounted Auxiliary Contacts: Comes equipped with factory-fitted auxiliary contacts (1 NO and 1 NC) and main circuit bars.

• Design Standard: Built in accordance with IEC 60947-4-1 standards for high reliability and safety.

Technical Specifications

• Manufacturer: ABB

• Series: AF Series (AF460)

• Product ID: 1SFL597001R7011

• Number of Poles: 3P (3 Main Contacts NO, 0 NC)

• Auxiliary Contacts: 1 NO / 1 NC

• Rated Operational Voltage ($U_e$): Main Circuit 1000 V

• Rated Operational Current AC-1 ($I_e$): 700 A @ 40°C / 600 A @ 55°C / 480 A @ 70°C (at 690 V and 1000 V)

• Rated Operational Current AC-3 ($I_e$): 460 A @ 55°C, 380–500 V / 400 A @ 55°C, 690 V / 200 A @ 55°C, 1000 V

• Rated Operational Power AC-3 ($P_e$): 250 kW @ 380/400 V / 250 kW @ 415/440 V / 315 kW @ 500 V / 355 kW @ 690 V / 280 kW @ 1000 V

• Conventional Free-Air Thermal Current ($I_{th}$): 700 A (at 40°C)

• Rated Control Circuit Voltage ($U_c$): 100…250 V 50/60 Hz and DC

• Rated Insulation Voltage ($U_i$): 1000 V (acc. to IEC 60947-4-1) / 600 V (acc. to UL/CSA)

• Rated Impulse Withstand Voltage ($U_{imp}$): Main Circuit 8 kV

• Mechanical Durability: 3 million cycles

• Operating Temperature: -40°C to +70°C (Note: Range is -25°C to +50°C when close to a contactor fitted with a thermal overload relay)

Dimensions & Weight

• Product Net Width: 186 mm

• Product Net Depth / Length: 216 mm

• Product Net Height: 278 mm

• Product Net Weight: 10.6 kg

Conclusion

The ABB AF460-30-11-70 3-pole magnetic contactor provides reliable power switching and motor control for industrial applications, featuring a wide control voltage range of 100–250 V AC/DC.

Contact Us

For pricing inquiries, system design, and stock availability in Bangladesh, get in touch with our team:

• Phone: +8801737118246

• Email: shaown@dreamtechnologiesbd.com
