Product Name: Ditek DTK-MRJ31XSCPWP Dialer Surge Protector Price in BD
Brand: Ditek
Product Overview
The Ditek DTK-MRJ31XSCPWP is a modular surge protection device for fire and security system dialer circuits. It installs in series with the dialer circuit at the point of use. It has an RJ31X In/Out connection through an RJ45 modular jack, with an external grounding screw. A patch cord is included.
The unit combines multi-stage hybrid protection with a 150 mA self-resetting sneak current protection (SCP) fuse. The fuse resets automatically, so the unit keeps protecting against repeated surges.
Key Features
- Single-pair RJ31X dialer circuit protection with patch cord
- RJ31X In/Out connection, 8 pins
- External grounding screw
- 150 mA self-resetting fuse (Sneak Current Protection)
- Multi-stage hybrid surge protection design
- Compact ABS housing
- 10-year limited warranty
Technical Specifications
Brand: Ditek
Model: DTK-MRJ31XSCPWP
Series: MRJ
Type: Modular surge protector (dialer circuit)
Connection: RJ31X In/Out, 8 pins
Agency approval: UL 497A
Protection modes: Pin 4 to Ground, Pin 5 to Ground
Peak surge current: 9,000 A
Max continuous current: 150 mA
Service voltage: Below 105 V AC
MCOV: 130 V AC
Operating temperature: Minus 40°C to 70°C (minus 40°F to 158°F)
Maximum humidity: 95% non-condensing
Dimensions: 43 × 76 × 30 mm (1.7″ × 3.0″ × 1.2″)
Weight: 113 g (4 oz)
Housing: ABS
Warranty: 10-year limited
Applications
Use it to protect the dialer circuit of fire alarm and security alarm control panels.
