Product Name: System Sensor 5604 194°F Heat Detector Price in Bangladesh
Product Overview
The System Sensor 5604 is a single-circuit mechanical heat detector. It has a fixed temperature rating of 194°F (90°C). In other words, it activates when the temperature at the detector reaches that point. System Sensor designed the 5600 series for property protection and for non-life-safety installations where smoke detectors are inappropriate.
The 5604 has normally open contacts and a reversible mounting bracket. Moreover, a collector drops from the unit when it activates. As a result, you can spot the detector in alarm at a glance.
Key Features
- Fixed temperature rating of 194°F (90°C), single circuit, normally open contacts
- Mechanical thermal sensor that is non-resettable, so you replace the detector after it activates
- Collector drops from the unit on activation
- Exterior lettering shows FX and 194°F / 90°C
- Reversible bracket for flush or surface mounting
- Screw terminals that accept 14 to 22 AWG wire
- UL 521 listing with 25 ft × 25 ft spacing
Technical Specifications
Brand: System Sensor
Model: 5604
Series: 5600
Type: Mechanical heat detector, single circuit
Activation: Fixed temperature only
Alarm temperature: 194°F (90°C)
Contacts: Normally open
Resettable: No, non-resettable
Listing: UL 521
Contact ratings: 6 to 125 VAC at 3 A; 6 to 28 VDC at 1 A; 125 VDC at 0.3 A; 250 VDC at 0.1 A
Input terminals: 14 to 22 AWG
Maximum installation temperature: 150°F (65.6°C)
Humidity: 5% to 95% RH, non-condensing
UL spacing (10 ft ceiling): 25 ft × 25 ft (7.62 m × 7.62 m)
Dimensions (with bracket): Diameter 4.57 in (11.6 cm), height 1.69 in (4.3 cm)
Weight: 6 oz (170 g)
Mounting: Single gang box, 3.5 in or 4 in octagonal box, 4 in square box with square to round plaster ring
Applications
Use the 5604 for property protection and non-life-safety installations where smoke detectors are inappropriate. However, install it only where the ambient temperature stays below its 150°F maximum installation temperature. Also, refer to NFPA 72 for spacing when ceilings exceed 10 feet.
Conclusion
The System Sensor 5604 gives fixed-temperature heat detection at 194°F in a single-circuit mechanical unit. Its reversible bracket fits common back boxes, and its collector shows the alarm clearly. Therefore, it suits locations where a smoke detector is not the right choice. Finally, remember to replace the detector after it activates.
